Enjoy crisp visuals and easy setup with Epson EB-W56S projector, designed for flexible workspaces and classrooms.

Take control of your presentations with Epson’s reliable, high-performance EB-W56S business projector. Whether you’re leading a boardroom meeting or teaching in a busy classroom, this projector deliver crystal-clear visuals that make your content shine. Flexible, user-friendly, and built to impress– Epson EB-W56S is your smart choice for impactful presentations, every time.

  • 3LCD technology for bright, vivid image quality
  • 3,700 lumens of colour and white brightness*1
  • WXGA resolution for clear, detailed images
  • Auto Vertical Keystone & Horizontal Slide Keystone
  • Built-in 16W speakers
  • Optional Wireless Capability

ค้นหาโปรแกรมเสริม

Projection Technology:

Projection Technology: RGB liquid crystal shutter projection system (3LCD)

Brightness*1:

White Light Output (Normal/Eco): 3,700 lm / 2,000 lmColour Light Output: 3,700 lmLight Output (Center)*2: 3,900 lm

Connectivity:

Network: Wired Lan : RJ45 x1
Wireless LAN : Optional (with ELPAP11)Analog Input: D-Sub 15pin : 2 (RGB, RGB Video)
RCA : 1Control: RS-232C : 1Digital Input: HDMI Type A : 2 (HDCP 1.4)Analog Output: D-Sub 15pin : 1 (RGB, RGB Video)Audio Input: RCA : 2
Stereo Mini : 2Audio Output: Stereo Mini : 1USB Input: USB Type A : 1 (For Wireless LAN, Firmware Update, Copy OSD Settings)
USB Type B : 1 (For Firmware Update, Copy OSD Settings)Mic Input: Stereo Mini : 1

Contrast Ratio:

Contrast Ratio: 16,000:1

Screen Size (Projected Distance):

Zoom : Wide: 50” – 300” [0.64 – 3.94 m]Zoom : Tele: 37” – 222” [0.64 - 3.94 m]

Geometric Correction:

Vertical/Horizontal Keystone: ±15° / ±15°

Operating Temperature:

Operating Temperature: Low Altitude (0 - 2,286m/7,500ft): 5 - 40 °C <41 - 104 °F>
High Altitude (Over 2,286m/7,500ft): 5 - 35 °C <41 - 95°F>
20% - 80% Humidity, No Condensation

Operating Altitude:

Operating Altitude: Over 1,500m/4,921ft with High Altitude Mode: 0 - 3,048m (0 -10,000ft)

Start-Up Period:

Start-Up Period: Less than 7 seconds (Epson Logo); Warm-up Period: 30 seconds

Cool Down Period:

Cool Down Period: Instant Off

Internal Speaker(s):

Sound Output: Monaural 16W x 1

Weight:

Weight: Approx. 3.1kg

Air Filter:

Maintenance Cycle*3: 10,000 hours (Normal) / 20,000 hours (Eco)

Fan Noise:

Fan Noise (Normal / Eco): 38dB / 28dB

Power Consumption (220-240V):

Lamp (Normal / Extended): Normal : 332 W
Extended : 231 WStandby (Normal / Eco) : 2.0/ 0.3 W

Direct Power On / Off:

Direct Power On / Off: Yes

Dimension Excluding Feet:

Dimension Excluding Feet (W x D x H): 309 x 282 x 90 mm

Wireless Specifications (Optional Wireless LAN):

Supported Mode: Infrastructure, Simple AP (Wi-Fi Direct)Supported Security Type: Infrastructure: Open, WPA2 / WPA3-PSK
Simple AP (Wi-Fi Direct): OPEN, WPA2-PSK (AES)Supported Speed : IEEE 802.11a/b/g/n

Wired LAN Specification:

Supported Speed for Each mode : IEEE 802.3i (10BASE-T), IEEE 802.3u (100BASE-TX)

Power Supply:

Power Supply Voltage: 100 - 240 V AC ±10%, 50/60 Hz

Specifications of Main Parts:

LCD: Size : 0.59” (C2 Fine)
Driving Method : Poly-silicon TFT active matrix
Pixel Number : 1,024,000 dots (1280 x 800) x 3
Native Resolution : WXGA
Aspect Ratio : 16:10
Pixel Arrangement : Cross stripeLight Source: Lamp Type : 230 W UHE
Life (Normal / Medium / Eco) : 6,500 hours / 10,000 hours / 17,000 hoursProjection Lens: Type : No Optical Zoom / Focus (Manual)
F-Number : 1.8
Focal Length : 7.8 mm
Zoom Ratio : 1.0 – 1.35 (Digital Zoom)
Throw Ratio : 0.60 – 0.81
ดูข้อมูลจำเพาะทั้งหมด ซ่อนรายละเอียดทั้งหมด
Print All Specs

หมายเหตุ:

*1 Colour brightness (colour light output) and white brightness (white light output) will vary depending on usage conditions. Colour light output measured in accordance with IDMS 15:4; white light output measured in accordance with ISO 21118.

*2 This light output value is measured at the centre of the screen as a reference value. There is no official standard for light output (Centre) measurements and this measurement is made based on the method set by Epson.

*3 When used in the general office environment (the amount of floating dust: 0.04 - 0.2 mg/m3). Based on the Epson’s in-house test results.
